Clique aqui para ver o Datasheet
Manufacturer: Texas Instruments
Product Category: Inverters
RoHS: Details
Number of Circuits: 6 Circuit
Logic Family: LS
Logic Type: Bipolar
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package / Case: PDIP-14
Packaging: Tube
Brand: Texas Instruments
Function: Inverter
High Level Output Current: - 0.4 mA
Input Type: TTL
Low Level Output Current: 8 mA
Number of Output Lines: 6 Output
Operating Supply Voltage: 5 V
Operating Temperature Range: 0 C to + 70 C
Output Type: CMOS
Product Type: Inverters
Propagation Delay Time: 22 ns
Series: SN74LS04
Subcategory: Logic ICs
Unit Weight: 1 g
